| Specifications | Hardware configuration: Processor: Dual-core 880MHz
 ROM: 16MB
 Product memory: 128MB DDR3
 2.4GHz Wi-Fi: 2×2 (Supports IEEE 802.11n protocol, up to a maximum speed of 300Mbps)
 5GHz Wi-Fi: 2×2 (Supports IEEE 802.11ac protocol, up to a maximum speed of 867Mbps)
 Antennas: 4 external omni-directional high performance antennas
 Cooling: Passive cooling
 Product ports:
 2x 10/100/1000M self-adaptive LAN port (Auto MDI/MDIX)1x 10/100/1000M self-adaptive WAN port (Auto MDI/MDIX)
 LED indicator: x2System reset button: x1
 Power supply port: x1
 Protocol standards: IEEE 802.11a/b/g/n/ac, IEEE 802.3/3u/3ab
 Wireless specifications:Dual-band:
 Modulation:
 11b:DSSS: DBPSK (1Mbps), DQPSK (2Mbps), CCK(5.5/11Mbps) 11a/g:OFDM: BPSK (6/9Mbps), QPSK (12/18Mbps), 16QAM (24/36Mbps),64QAM (48/54Mbps) 11n:MIMO-OFDM:BPSK, QPSK, 16QAM, 64QAM. Rate set: MCS0-MCS15 11ac:MIMO-OFDM:BPSK, QPSK, 16QAM, 64QAM, 256QAM.
 Rate set: MCS0 to MCS9 (supports 2 streams) Software parameters:Operating system: OpenWRT widely customisable intelligent router operating system MiWiFi ROM
 Wireless security: WPA-PSK/WPA-PSK2 encryption, wireless access control (black and white lists), SSID hiding, smart anti-hacking protection
 Manage applications: Support Web, Android, iOS
 Operating environment:Operating environment temperature: 0°C–40°C
 Operating humidity: 10%–90% RH (non-condensing)
 Storage temperature: -40°C–70°C
 Storage temperature: 5%–90% RH (non-condensing)
 Package contents:Main unit
 User manual
 Power cable
 |
|---|
